Diodes IncorporatedSMBJ33CA-13-FTVS
TVS Diode Single Bi-Dir 33V 600W 2-Pin SMB T/R
- Buy Options
- Information
| EU RoHS | Compliant with Exemption |
| ECCN (US) | EAR99 |
| Part Status | Active |
| HTS | 8541.10.00.80 |
| Configuration | Single |
| Direction Type | Bi-Directional |
| Number of Elements per Chip | 1 |
| Minimum Breakdown Voltage (V) | 36.7 |
| Maximum Clamping Voltage (V) | 53.3 |
| Maximum Reverse Stand-Off Voltage (V) | 33 |
| Maximum Peak Pulse Current (A) | 11.3 |
| Maximum Reverse Leakage Current (uA) | 5 |
| Test Current (mA) | 1 |
| Peak Pulse Power Dissipation (W) | 600 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Operating Temperature (°C) | 150 |
| Maximum Power Dissipation (mW) | 5000 |
| Supplier Temperature Grade | Commercial |
| Product Weight (g) | 0.1 |
| Packaging | Tape and Reel |
| Standard Package Name | DO-214-AA |
| Pin Count | 2 |
| Supplier Package | SMB |
| Mounting | Surface Mount |
| Package Height | 2.3(Max) |
| Package Length | 4.57(Max) |
| Package Width | 3.94(Max) |
| PCB changed | 2 |
| Lead Shape | J-Lead |
Diodes Zetex's SMBJ33CA-13-F TVS diode is designed to protect electronic components and circuits from electrical overstress from overvoltage and electrostatic discharge. Its maximum leakage current is 5 μA. Its peak pulse power dissipation is 600 W. Its test current is 1 mA. This device's maximum clamping voltage is 53.3 V and minimum breakdown voltage is 36.7 V. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 150 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment.
