Analog DevicesADG1421BRMZAnalog Switch Multiplexers

Manufacturer

Analog Switch Dual SPST 10-Pin MSOP Tube

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Type	Analog Switch
Configuration	Dual SPST
Switch Architecture	SPST
Number of Channels per Chip	2
Number of Inputs per Chip	2
Number of Outputs per Chip	2
Chip Enable Signals	Yes
Polarity	Non-Inverting
Maximum Turn-On Time (ns)	370@±5V
Maximum Turn-Off Time (ns)	295@±5V
Maximum Frequency (25°C) @ Vcc (MHz)	180(Typ)@±15V\|150(Typ)@±5V\|140(Typ)@12V
Input Signal Type	Single
Output Signal Type	Single
Minimum Single Supply Voltage (V)	5
Typical Single Supply Voltage (V)	12
Maximum Single Supply Voltage (V)	16.5
Minimum Dual Supply Voltage (V)	±4.5
Typical Dual Supply Voltage (V)	±15\|±5
Maximum Dual Supply Voltage (V)	±16.5
Typical Supply Current (mA)	±0.000001@±5.5V
Maximum Supply Current (mA)	±0.001@±5.5V@-40C to 125C
Maximum On Resistance (Ohm)	5.2@±5V
Maximum On Resistance Range (Ohm)	5 to 10
Power Supply Type	Dual\|Single
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	125
Supplier Temperature Grade	Industrial
Packaging	Tube
Standard Package Name	SOP
Pin Count	10
Supplier Package	MSOP
Mounting	Surface Mount
Package Height	0.85
Package Length	3
Package Width	3
PCB changed	10
Lead Shape	Gull-wing
