Grayhill Electromechanical Switches

Part No.	Price	Stock	Manufacturer	Product Category	Pole Throw Configuration	Switch Configuration	Maximum Current Rating - (A)	Minimum Insulation Resistance - (MOhm)	Maximum Contact Resistance - (mOhm)	Electrical Life - (Cycles)	Mechanical Life - (Cycles)	Termination Style	Contact Material	Operating Temperature - (°C)	Packaging	Military

Part No.	Price	Stock	Manufacturer	Product Category	Pole Throw Configuration	Switch Configuration	Maximum Current Rating - (A)	Minimum Insulation Resistance - (MOhm)	Maximum Contact Resistance - (mOhm)	Electrical Life - (Cycles)	Mechanical Life - (Cycles)	Termination Style	Contact Material	Operating Temperature - (°C)	Packaging	Military
71BDF36-02-2-AJN Switch Rotary DP5T 5 Flatted Shaft PC Pins 0.3A 115VAC 30VDC Automotive	1+ $25.86 7+ $24.62 13+ $23.51 25+ $22.49 Increments of 1	Stock 77 From $22.49 to $25.86 Per Unit Ships in 3 days	Grayhill	Switch Rotary	DP5T		0.3@115VAC	1000	50	25000(Max)		PC Pins	Silver Alloy/Beryllium Copper			No
76PSB12ST Switch DIP ON OFF SPST 12 Piano 0.15A 30VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube	Per Unit $1.365 Increments of 1	Stock 6 $1.365 Per Unit Ships tomorrow	Grayhill	Switch DIP	SPST	ON OFF	0.15@30VDC	5000	<=30	2000	2000	PC Pins	Copper Alloy	-40~85	Tube	No
71BD30-02-1-AJN Switch Rotary SP12T 12 Flatted Shaft Solder Lug 0.3A 115VAC 30VDC	2+ $21.22 7+ $20.20 13+ $19.28 25+ $18.44 Increments of 1	Stock 30 From $18.44 to $21.22 Per Unit Ships in 3 days	Grayhill	Switch Rotary	SP12T		0.3@115VAC	1000	50	25000(Max)		Solder Lug	Silver Alloy/Beryllium Copper			No
95CW06B3RART Switch Tactile N.O. SPST Round Button PC Pins 0.05A 12VDC 2.55N Thru-Hole T/R	1+ $2.7669 10+ $2.5484 25+ $2.4369 100+ $2.2218 250+ $2.1367 500+ $1.8860 1000+ $1.8607 Cut Strips 1+ $2.7669 10+ $2.5484 25+ $2.4369 100+ $2.2218 250+ $2.1367 500+ $1.8860 1000+ $1.8607 View More Increments of 1	Stock 8,402 From $1.8607 to $2.7669 Per Unit Ships tomorrow	Grayhill	Switch Tactile	SPST	N.O.	0.05@12VDC	100	100	500000		PC Pins	Stainless Steel	-25~70	Tape and Reel	No
39-101-EW Switch Push Button N.O. SPST Round Button 1A Momentary Contact Panel Mount Wire Lead	Per Unit $19.11 Increments of 1	Stock 2 $19.11 Per Unit Ships tomorrow	Grayhill	Switch Push Button	SPST	N.O.	1	1000	25			Wire Lead				No
71C2054 Switch Access PC Mount Accessory Rotary Switch Automotive	Per Unit $0.798 Increments of 1	Stock 2 $0.798 Per Unit Ships tomorrow	Grayhill	Switch Accessories												No
78RB03ST Switch DIP OFF ON SPST 3 Recessed Slide 0.15A 30VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube	Per Unit $0.7024 Increments of 1	Stock 2 $0.7024 Per Unit Ships tomorrow	Grayhill	Switch DIP	SPST	OFF ON	0.15@30VDC	5000	<=30	2000	2000	PC Pins	Copper Alloy	-40~85	Tube	No
50J1066 Non-turn washer used with Rotary Switch, fits double D bushing flats, military and standard for 1/8" diameter shafts	1+ $0.4317 10+ $0.3172 Increments of 1	Stock 39 From $0.3172 to $0.4317 Per Unit Ships tomorrow	Grayhill	Switch Accessories											Bulk	No
90B10ST Switch DIP ON OFF SPST 10 Recessed Slide 0.15A 30VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube	10+ $2.50 16+ $2.16 1000+ $1.45 Increments of 1	Stock 1,880 From $1.45 to $2.50 Per Unit Ships in 3 days	Grayhill	Switch DIP	SPST	ON OFF	0.15@30VDC	5000	<=20	2000	2000	PC Pins	Copper Alloy	-40~85	Tube	No
94HBB16RAT Switch DIP N.O./N.C. SP16T 16 Knob 0.03A 30VDC PC Pins 10000Cycles 2.54mm Thru-Hole Tube	Per Unit $3.094 Increments of 1	Stock 1 $3.094 Per Unit Ships tomorrow	Grayhill	Switch DIP	SP16T	N.O./N.C.	0.03@30VDC	5000	50	10000	10000	PC Pins	Copper Alloy	-40~85	Tube	No
78B04SRAT Switch DIP OFF ON SPST 4 Raised Slide 0.15A 30VDC PC Pins 2000Cycles 2.54mm Thru-Hole	8+ $3.53 11+ $3.20 21+ $3.06 1000+ $2.11 Increments of 1	Stock 1,507 From $2.11 to $3.53 Per Unit Ships in 3 days	Grayhill	Switch DIP	SPST	OFF ON	0.15@30VDC	5000	30	10000	2000	PC Pins	Copper Alloy	-40~85		No
71BDF30-01QAJN Switch Rotary DP6T 6 Flatted Shaft PC Pins 0.3A 115VAC 30VDC Automotive	Per Unit $24.035 Increments of 1	Stock 1 $24.035 Per Unit Ships tomorrow	Grayhill	Switch Rotary	DP6T		0.3@115VAC	1000	50	25000(Max)		PC Pins	Silver Alloy/Beryllium Copper			No
94HFC16WT Switch DIP N.O./N.C. SP16T 16 Flush Screwdriver 0.03A 30VDC Gull Wing 10000Cycles 2.54mm SMD Tube	8+ $3.28 14+ $2.98 27+ $2.84 Increments of 1	Stock 54 From $2.84 to $3.28 Per Unit Ships in 3 days	Grayhill	Switch DIP	SP16T	N.O./N.C.	0.03@30VDC	5000	50	10000	10000	Gull Wing	Copper Alloy	-40~85	Tube	No
46-110 BLK Switch Push Button N.O./N.C. SPDT Round Button 0.25A 220VAC Momentary Contact Solder Panel Mount	4+ $7.12 7+ $6.77 13+ $6.47 Increments of 1	Stock 13 From $6.47 to $7.12 Per Unit Ships in 3 days	Grayhill	Switch Push Button	SPDT	N.O./N.C.	0.25@115VAC	1000	<25	250000		Solder		-40~85		No
94HAB16T Switch DIP N.O./N.C. SP16T 16 Flush Screwdriver 0.03A 30VDC PC Pins 10000Cycles 2.54mm Thru-Hole Tube	1+ $2.721 10+ $2.625 25+ $2.326 100+ $2.040 250+ $1.819 500+ $1.504 View More Increments of 1	Stock 908 From $1.504 to $2.721 Per Unit Ships tomorrow	Grayhill	Switch DIP	SP16T	N.O./N.C.	0.03@30VDC	5000	50	10000	10000	PC Pins	Copper Alloy	-40~85	Tube	No
76P05 Switch Access Protective Cover DIP Switch	1+ $0.8096 10+ $0.6703 25+ $0.6607 50+ $0.6512 100+ $0.5066 Increments of 1	Stock 257 From $0.5066 to $0.8096 Per Unit Ships tomorrow	Grayhill	Switch Accessories												No
23C1024-1 Switch Access Nut Push Button Switch	10+ $2.53 13+ $2.30 25+ $2.21 Increments of 1	Stock 67 From $2.21 to $2.53 Per Unit Ships in 3 days	Grayhill	Switch Accessories										-40~85		No
44A45-01-2-02N Switch Rotary DPDT 2 Flatted Shaft Solder Lug 5A 115VAC 28VDC	1+ $44.95 3+ $42.82 5+ $40.87 Increments of 1	Stock 9 From $40.87 to $44.95 Per Unit Ships in 3 days	Grayhill	Switch Rotary	DPDT		5@115VAC	1000	50	25000	100000	Solder Lug	Silver Alloy			No
76SB12T Switch DIP ON OFF SPST 12 Raised Rocker 0.15A 30VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube	Per Unit $2.40 Increments of 1	Stock 81 $2.40 Per Unit Ships in 3 days	Grayhill	Switch DIP	SPST	ON OFF	0.15@30VDC	5000	<=30	2000	2000	PC Pins	Copper Alloy	-40~85	Tube	No
76PSB06T Switch DIP ON OFF SPST 6 Piano 0.15A 30VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube	11+ $2.41 15+ $2.10 1000+ $1.38 2500+ $1.08 Increments of 1	Stock 4,863 From $1.08 to $2.41 Per Unit Ships in 3 days	Grayhill	Switch DIP	SPST	ON OFF	0.15@30VDC	5000	<=30	2000	2000	PC Pins	Copper Alloy	-40~85	Tube	No
30-2 Switch Push Button N.C. SPST Round Button 1A 220VAC Momentary Contact Solder Lug Panel Mount	7+ $3.84 13+ $3.49 25+ $3.34 100+ $3.11 Increments of 1	Stock 220 From $3.11 to $3.84 Per Unit Ships in 3 days	Grayhill	Switch Push Button	SPST	N.C.	1@115VAC	1000	25	1000000		Solder Lug		-40~85		No
90HBW05PT Switch DIP ON OFF SPST 5 Recessed Slide 0.1A 30VDC Gull Wing 2000Cycles 2.54mm SMD Tube	9+ $2.88 16+ $2.62 31+ $2.51 Increments of 1	Stock 369 From $2.51 to $2.88 Per Unit Ships in 3 days	Grayhill	Switch DIP	SPST	ON OFF	0.1@6VDC	5000	20	2000	2000	Gull Wing	Copper Alloy	-40~85	Tube	No
78RB07ST Switch DIP OFF ON SPST 7 Recessed Slide 0.15A 30VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube	11+ $2.33 13+ $2.02 Increments of 1	Stock 147 From $2.02 to $2.33 Per Unit Ships in 3 days	Grayhill	Switch DIP	SPST	OFF ON	0.15@30VDC	5000	<=30	2000	2000	PC Pins	Copper Alloy	-40~85	Tube	No
39-424 BLK Switch Push Button N.O. SPST Round Plunger 0.15A 28VDC Momentary Contact Panel Mount/Through Hole PC Pins	Per Unit $4.15 Increments of 1	Stock 75 $4.15 Per Unit Ships in 3 days	Grayhill	Switch Push Button	SPST	N.O.	0.15@28VDC	1000	25	100000		PC Pins		-40~85		No
76HPSB08GWRT Switch DIP ON OFF SPST 8 Piano 0.15A 30VDC Gull Wing 2000Cycles 2.54mm SMD T/R	1+ $2.893 10+ $2.601 25+ $2.575 100+ $2.349 250+ $2.329 Cut Strips 1+ $2.893 10+ $2.601 25+ $2.575 100+ $2.349 250+ $2.329 View More Increments of 1	Stock 930 From $2.329 to $2.893 Per Unit Ships tomorrow	Grayhill	Switch DIP	SPST	ON OFF	0.15@30VDC	2000	30	2000	2000	Gull Wing	Copper Alloy	-40~85	Tape and Reel	No
